48VDC / 15000 Watt 3Ph TELECOM Battery Charger

Post
Capacity   KVA

800

Compact
substation – Enclosure

Height
(mm)

2800

Width
(mm) – MV or LV panel access sides

4200

Depth
(mm) – left or right sides

2700

Ventillation Type

Natural

Design
site Condition Temperature  (°C)

40

Altitude
(m)

1000

Humidity
%

90

Rated
Power  kVA

800

IP

23

Enclosure
Weight (app)  Kg

≈2600

Compact
SubstationTotal Weight (Kg)

≈6150

Standard

IEC62271-202

Compact
substation – MV Switchgear

Rated
Voltage  (KV)

36

Operational
Voltage  (KV)

33

Rated
Power Frequency Withstand Voltage  (KV)

75

Rated
Lighting Impulse Withstand Voltage  (KV)

195

Rated
Frequency   ( HZ)

50

Rated
Current   (A)

630

Rated
Short Time Current (1sec) – KA

16

Control
Voltage  ( V AC )

230

Degree
of Protection (IP)

2X

Circuit
Breaker

VACUUM

Weight
(Kg)

≈700

Standard

62271-200

Compact
substation – LV Switchgear

Rated
Voltage  (V)

690

Operational
Voltage  (V)

400

Rated
Power Frequency Withstand Voltage (V)

2000

Rated
Frequency  (HZ)

50

Rated
Current   (A)

1154

Rated
Short Time Current (1sec) – KA

50

Control
Voltage   (V AC & DC)

230 AC/220DC

Degree
of Protection (IP)

42

Circuit
Breaker  Rated Current  (A)

1600

Weight
(Kg)

≈3500

Standard

IEC61439-1&2

Compact
substation – Transformer

Rated
Power  (KVA)

800

Type

OIL/DRY

Vector
Group

DYN5

Impedens    %

6%

Primery Voltage  (KV)

20

Secendary Voltage   (V)

400

Secendary Current   (A)

1154

Weight
(Kg)

≈2500

Standard

IEC60076
